Overview

Emergency information from the Defender owner’s handbook shown above (2nd edition, 2001; covers Tdi and Td5 diesels).

Fuses (pp. 142-143)

• Main fuse box: below the steering column, cover held by screws
• Spare fuses: on the underside of the fuse box cover
• Colours: violet 3 A, tan 5 A, brown 7.5 A, red 10 A, blue 15 A, yellow 20 A, white 25 A, green 30 A

Jump starting (pp. 138-139)

• Push or tow starting is not recommended
• Red lead: + of the donor battery to + of the flat battery
• Black lead: – of the donor battery to a bare metal earth point at least 0.5 m from the flat battery

FAQ

Can it be towed on all four wheels?
Yes. Put the main gearbox and the transfer box in neutral, unlock the diff lock and turn the key to position I to unlock the steering (p. 140).

Can I tow a trailer from the towing eyes?
No, they are only for recovering the vehicle on the road (p. 140).

What about towing with one axle lifted?
The propeller shaft to the axle left on the ground must be disconnected first, because the Defender has permanent four-wheel drive (p. 141).
